1. Definition of Pin Wiring for Reci Tottenham Hotspur Laser
Definition of Pin Wiring for Reci Tottenham Hotspur Laser The pin wiring definition for Reci Tottenham Hotspur Laser is mainly based on the 16 core control wire of its CTRL-INTERFACE interface wire. The following is a detailed definition and explanation of these pin connections:
1. Definition of 16 core control wire for CTRL-INTERFACE interface wire According to the provided image information, the 16 core control wire for CTRL-INTERFACE interface wire is defined as follows: Pin 1 (Brown): Laser Enable, used to control the on and off of the laser. Pin 2 (Blue): Laser Power Adjust, used to adjust the output power of the laser. Pin 3 (White): Laser Mode Select, used to select different operating modes of the laser. Pin 4 (Green): Reserved, currently not in use, but can be used for future expansion or specific functionality. Pin 5 (Black): Ground, providing grounding for the entire control system. Pin 6 (Red): Alarm Output, which outputs an alarm signal when the laser malfunctions or is abnormal. Pin 7 (Orange): Reserved, currently unused, but can be used for future expansion. Pin 8 (Yellow): External Trigger Input, used to receive external signals to trigger the start of the laser. Pin 9 (Gray): Reserved, not used. Pin 10 (Purple): Reserved, not used. Pin 11 (Brown/White Stripe): Cooling Water Flow Monitor, used to monitor the flow of cooling water and ensure that the laser operates under safe conditions. Pin 12 (Blue/White Stripe): Cooling Water Temperature Monitor, used to monitor the temperature of cooling water and prevent laser overheating. Pin 13 (Green/White Stripe): Reserved, not used. Pin 14 (Gray/White Stripe): Laser Status Output, used
III. Precautions: When starting the laser, the correct startup sequence should be followed.
. Firstly, turn the laser key to the ON position, and then press the start button on the laser panel. In this way, the laser will be powered on and ready for normal welding. In the next welding, simply power on directly without repeating the above startup actions. Safe operation: When operating the laser, relevant safety operating procedures should be strictly followed. For example, when the laser is running, direct observation of the laser beam should be avoided to avoid eye damage. At the same time, it is necessary to ensure the safety of the Zhenpei sail work area and prevent accidental injuries caused by scattering or reflection of laser beams. Maintenance: Regular maintenance of the laser is key to ensuring its long-term stable operation. This includes cleaning the laser surface, inspecting the cooling system, replacing aging components, etc. Through regular maintenance, potential faults and hidden dangers can be detected and eliminated in a timely manner, improving the service life and performance of th
