1. Price range for various flow meters

There are too many types of flow meters, I can only give you a rough idea and cannot list them one by one. As someone who specializes in flow meters, I will tell you that the small bracket WR-1000HSIZ DN15-100MM costs 6800 yuan, the medium bracket WR-1000HMIZ DN50-700MM costs 7000 yuan, and the operating temperature is 0-80 degrees with an accuracy of 1% and a built-in power supply of 90-220VAC. Fuji expansion protocol standard configuration: host+standard M1 sensor+signal cable+protective box. Electromagnetic flow meters are generally priced at 2800 yuan for DN10-50 and 2800 yuan for PTFE sparrow bend inner village. 2700 yuan for rubber inner village vortex street flow meters are generally priced at 2300 yuan for DN10-50. I am engaged in special discussions for flow meters. Ill tell you the specifications, vortex street prices, electromagnetic prices, glass rotor prices for nuclear leak meters DN25 300DN40 100 400DN50 550DN80 1000DN100 1200DN200 DN300 I hope I can help you with the specifications and prices of the Velbar flowmeter DN50 3500DN80 4000DN100 4200DN125 4600DN150 5000DN200 6000DN250 7000DN300 7800DN350 8160DN400 9000DN500 9840DN600 10800DN700 11400DN800 12000DN900 13200DN1000 14400DN1200 15600DN1400 18000DN1600 20400DN1800 22800

2. Overview of steam flowmeter?

1. Overview LFX rotor type steam flowmeter is a specialized instrument for measuring the cumulative mass flow of steam, with two structural types: mechanical and intelligent.; Through the indicator dial (mechanical) or LCD display screen (intelligent) on-site display, the quality of all steam flowing through the meter can be accurately read,

and pulse signals can also be output. It also has manual pressure compensation or automatic temperature compensation functions. Due to its simple structure, moderate price, and wide measurement range, this flowmeter is widely used in industries such as petroleum, chemical, textile, and heating that require steam flow measurement.

2. Working principle: When the measured steam flows through the flowmeter body, it is throttled by the orifice plate. Under the action of the front and rear pressure difference, a part of the steam enters the nozzle of the diversion pipe, and the jet formed by the nozzle pushes the upper end of the rotor shaft to rotate. There are two damping blades at the lower end of the rotor shaft that rotate in a damping chamber filled with damping fluid, so that the wing wheel can fully absorb the kinetic energy of the jet.

. When the rotational torque of the wing wheel is balanced or different from the damping torque, the rotational speed of the wing wheel is proportional to the mass flow rate of the measured steam flowing through the flowmeter. Through correction and division, the actual flow rate of accumulated steam is reflected by the indicator dial.

III. Main Parameters and Performance Indicators

1. Measurement of saturated steam and slightly superheated steam (superheat ≤ 20 ℃)

2. nominal diameter 02;

; 05; 08; 10;

3、 The maximum working temperature is 183 ℃ (02) and 240 ℃ (05; 08; 10);

4、 The ambient temperature is only required for intelligent devices, ranging from 0 ℃ to 55 ℃ (special orders are placed for temperatures exceeding this range). 5. The pressure range for use is 0.03-1.0 MPa (02) 0.05-1.6 MPa (05; 08; 10);

6、 Installation meth
