Flow Meter Setting Tutorials: Configuring Transmitter Span, Zero Points, and Low-Flow Cutoffs
Quick Answer: Set the transmitter span first using the actual process flow range, not the sensor maximum. Then complete a zero point calibration with a full pipe and no flow and set the low flow cutoff at 0.5 percent to 2 percent of full scale depending on meter type. This removes false totalizer counts and keeps the 4-20 mA signal stable.
Why Field Settings Differ from Factory Default Settings
This flow meter setting tutorial focuses on three transmitter parameters that cause most field complaints: span, zero point, and low flow cutoff. Silver Automation Instruments ships flow meters with a factory span and zero point that match the sensor size. A DN80 electromagnetic flow meter may leave the factory with a span of 0 to 100 cubic meters per hour. A Coriolis mass flow meter may leave with a span of 0 to 5000 kilograms per hour. Field conditions are different. A cooling water line in a Malaysian semiconductor plant may only run between 2 and 15 cubic meters per hour. If the span stays at 0 to 100 cubic meters per hour, the 4-20 mA output uses only a small part of the range. Control room resolution drops. Low flow noise becomes more visible.
Here is the thing. The span setting is not about sensor capability. It is about the actual process range. Engineers who skip this step often blame the meter for unstable output. We have seen this on customer sites many times. The problem is normally a transmitter range that is too wide.
Configure Transmitter Span for 4-20 mA and HART Output
Start with minimum flow, normal flow, and maximum flow in one unit. For electromagnetic flow meters use cubic meters per hour or liters per second. For Coriolis and thermal mass flow meters use kilograms per hour or standard cubic meters per hour. For oval gear flow meters use liters per minute.
Set the LRV lower range value to the minimum expected flow. For a DN50 electromagnetic flow meter on a dosing skid in Vietnam, that might be 0 liters per minute. Set the URV upper range value to the maximum flow with a small margin. If normal flow is 100 liters per minute and maximum flow is 140 liters per minute, set the span at 0 to 160 liters per minute. The 20 mA point equals 160 liters per minute. The 4 mA point equals 0 liters per minute. This is direct and avoids a signal that saturates during normal production.
For a Coriolis mass flow meter on crude palm oil in Indonesia, a typical span is 0 to 2000 kilograms per hour. The transmitter maps 4 mA to 0 kilograms per hour and 20 mA to 2000 kilograms per hour. The HART signal reads the same process variable. Do not set the span only from the sensor maximum of 5000 kilograms per hour if the line never exceeds 1500 kilograms per hour.
Zero Point Calibration Without Guesswork
Zero point calibration works only with a full pipe and no flow. For electromagnetic flow meters, close the downstream valve and keep the upstream valve open. The sensor tube must be completely filled. If there is no isolation valve, stop the pump and wait for the pipe to become static. Air bubbles or an empty pipe will shift the zero point. Industrial water and wastewater lines above 50 µS/cm normally give a stable signal. In a water treatment plant in the Philippines, we often see a zero error because the pipe drains back after pump shutdown. A partial pipe produces a false flow signal.
For Coriolis mass flow meters, the zero procedure is different. Close the downstream block valve and fill the meter with the actual process fluid at operating temperature. Wait 5 to 10 minutes for the sensor temperature to stabilize. Run the zero calibration from the transmitter menu. The drive frequency and tube vibration then settle. You can verify with the zero stability value. For a polyurethane chemical line at 45 degrees Celsius and 120 cP, a stable zero check might take 15 minutes because viscosity changes with temperature.
Most engineers skip this part. They run zero calibration once at cold start and then wonder why the totalizer drifts later. Repeat the zero check after a long shutdown. Repeat it after changing fluid type or viscosity. A paint manufacturer in Southeast Asia had a batch totalizer drift of 2 percent on solvent based resin. The cause was a ze
_600x400.jpg)
Set Low Flow Cutoff to Stop False Totalizer Counts
Low flow cutoff is a threshold below which the transmitter forces flow output to zero. It prevents the meter from counting noise, valve leakage, or natural convection movement. The correct value depends on meter type and process stability.
For electromagnetic flow meters, a starting point is 0.5 percent of full scale. With a span of 0 to 160 liters per minute, set the low flow cutoff at 0.8 liters per minute. If the signal is still unstable, increase it to 1 percent. Do not set it to 5 percent unless you are certain the process never operates below 8 liters per minute. A water utility in Kenya lost billing on small night flows because the cutoff was set too high at 3 percent of full scale.
For Coriolis mass flow meters, a low flow cutoff of 0.2 percent to 0.5 percent of rated flow is common. A 2000 kilograms per hour meter can have a cutoff at 4 kilograms per hour. For batching applications with additives, keep it low. A chemical plant in Vietnam dosing inhibitor at 10 to 50 kilograms per hour should set the cutoff at 1 kilogram per hour or less.
For thermal mass flow meters on compressed air, set the cutoff based on minimum operating flow. If a compressor unloads at 50 standard cubic meters per hour and the span is 0 to 500 standard cubic meters per hour, a cutoff of 10 standard cubic meters per hour is reasonable. This stops zero drift but still records the true load when the compressor runs.
Recommended Silver Instruments Models and Setup Ranges
Silver Automation Instruments is a flow meter manufacturer and supplier for water, oil and gas, chemical, food and beverage, and marine applications. For water and wastewater, the DN10 to DN300 electromagnetic flow meter with 4-20 mA HART is the standard choice. For palm oil, diesel, and chemical batching, the Coriolis mass flow meter with RS485 Modbus and HART works well. For compressed air and biogas, the thermal mass flow meter with inline insertion probe is common. For a biogas line in the Middle East with ATEX Zone 1 classification, use a meter with the correct hazardous area certification and PT100 temperature input where gas temperature compensation is required.
A typical setup for a seawater desalination plant in Australia would be a DN150 electromagnetic flow meter with a span of 0 to 80 liters per second, zero calibration at full pipe, and low flow cutoff at 0.4 liters per second. A typical setup for a diesel generator fuel line in Nigeria would be an oval gear flow meter with a span of 0 to 500 liters per hour and a low flow cutoff at 2 liters per hour.
Send us your pressure (bar), temperature (°C), pipe size (DN), and flow range. We will recommend a meter span and cutoff that fits your process. Contact Tel: +86-25-68650347, Whatsapp: +86-25-52155837, WeChat: +86 15365082610.
FAQ
What span should I set for a 4-20 mA electromagnetic flow meter?
Set 4 mA to zero flow and 20 mA to the maximum expected flow with 10 percent margin. If normal flow is 90 cubic meters per hour, set 20 mA at 100 cubic meters per hour.
Why does my flow meter show flow when the pump is off?
The pipe may not be completely full or the zero point has drifted. Install the sensor at a low point to keep it full and repeat zero calibration under no flow conditions.
What low flow cutoff is correct for a Coriolis mass flow meter?
Start at 0.2 percent to 0.5 percent of rated flow. For a 2000 kilograms per hour meter, that means 4 to 10 kilograms per hour. Do not hide real batch flow with a high cutoff.
Can I use one low flow cutoff for different products?
No. Viscosity and density change the signal. A light solvent and a heavy oil need different cutoff values. Save separate parameter sets if your transmitter supports multiple configurations.
Does Silver Instruments provide remote support for commissioning?
Yes. Send us your flow range, pipe size (DN), process fluid, pressure (bar), temperature (°C), and output type. Our engineers can check your span, zero point, and cutoff settings before you start calibration. Contact Tel: +86-25-68650347, Whatsapp: +86-25-52155837, WeChat: +86 15365082610.
